Camera

• Image Sensor5 MP CMOS
• Signal SystemPAL/NTSC
• Frame RateTVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fpsCVI: 4MP@30fps, 4MP@25fpsAHD: 5MP@20fps, 4MP@30fps, 4MP@25fpsCVBS: PAL/NTSC
• Resolution2560 (H) × 1944 (V)
• Min. illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50, 000 sNTSC: 1/30 s to 1/50, 000 s
• Lens2.8 mm, 3.6 mm, 6 mm fixed lens
• Horizontal Field of View2.8 mm, horizontal FOV: 85.5°,vertical FOV: 63.7°, diagonal FOV: 110.7°3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9°6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5°
• Lens MountM12
• Day & NightICR
• Angle AdjustmentPan: 0 to 355°, Tilt: 0 to 75°, Rotation 0 to 355°

Menu

• AGCSupport
• Day/Night ModeAuto/Color/BW (Black and White)
• White BalanceATW/MANUAL
• BLC (Backlight Compensation)Yes
• LanguageEnglish
• FunctionsBrightness, Sharpness, Mirror, Smart IR

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
• Power Supply12 VDC ± 25%*You are recommended to use one power adapter to supply the power for one camera.
• Power ConsumptionMax. 3.7 W
• Protection LevelIP67
• MaterialPlastic
• IR RangeUp to 25 m
• CommunicationHIKVISION-C
• Dimensions58 mm × 61 mm × 158.6 mm (2.28" × 2.40" × 6.42")
• WeightApprox. 160 g (0.35 lb.)
